處理器( CPU ) | ARM7, 32 bit RISC, 100MIPS |
內存( Memory ) | RAM: 8M SDRAM Flash ROM: 2M NOR + 16M NAND ( for Data Storage ) , extendable, up to 8M (NOR) + 128M (NAND) |
顯示( Display ) | LCD 160 X 128, 4 Level Gray, EL back-light |
鍵盤( Keys ) | 23 Keys |
通訊( Communication ) | RS232 : 9600 – 115200 bps IrDA* : SIR 9600 – 115200 bps RS485 (in cradle): 9600 – 115200 bps |
廣域無線通訊( Wireless ) | 可選 : GSM/GPRS or Mobitex (Optional) |
局域無線通訊( Wireless ) | 可選 : 433MHz RF (Optional) |
操作系統與開發工具 ( Operating System & Developing Tools ) | Operating System: uBase-III ** ( Real-Time, Multi-Task ) or Linux Developing Tools: uTools 2.0 ( MS Visual C++6.0 Add-in ) |
電池( Battery ) | 850mAH Li-Battery, 同 NOKIA 3310,3330 手機電池兼容 |
電源( Power ) | Power supply: DC5.6V, 1.5A AC Power: AC100~240V, 50~60HZ |
外形( Dimensions ) | 最大部分: 200mm(L) X 72mm(W) X 35mm(H) 手握部分: 55mm(W) X 22mm(H) |
重量( Weight ) | 350g ( with GPRS module ) |
功耗( Consumption ) | Standby:20mW, Normal:500mW, Max:1.5W (Laser On) |
識讀組件( Scan Modul ) | Symbol SE1200WA, 或:攝像式識讀頭(可讀二維碼) |
一次充電識讀次數 | >5000 |
識讀方式( Reading Mode ) | Laser or Image |
識讀距離( Scan Distance ) | 38 ~ 584mm |
識讀精度( Precision ) | 5 ~ 55mil |
識讀碼制( Symbologies ) | 1D : UPC, EAN, Code39, Code128, Interleaved 2 of 5, etc 2D : PDF417, QR, DataMatrix |
工作溫度 ( Operating Temperature ) | -5 C o to +40 C o |
工作濕度 ( Operation Humidity ) | 5% - 95% ( non-condensing ) |
環境照度( Ambient Light ) | 0 ~ 100,000 Lux |
跌落高度( Drop ) | 1.2 meter, to concrete |
工業等級 ( Construction Features ) | IP54 |
